geometry/tools/exampleQuickHull3D.cpp

Computation of the convex hull of a list of 3D points by Quick Hull algorithm.

# Computes the convex hull of examples/samples/bunny.dat with precision 100
./examples/geometry/tools/exampleQuickHull3D

outputs

Read 13230 3D points.
Domain l=[PointVector] {-95, -135, -68} u=[PointVector] {6114, 4743, 6186}
[BoundedRationalPolytope<3> A.rows=2104 valid_edge_constraints=0 denom=100]
  [ 100 0 0 ] . x <= 6114
  [ -100 0 0 ] . x <= 95
  [ 0 100 0 ] . x <= 4743
  [ 0 -100 0 ] . x <= 135
  [ 0 0 100 ] . x <= 6186
  [ 0 0 -100 ] . x <= 68
  [ -92731200 -234892700 -352348000 ] . x <= 264145202
  [ -200106200 -500176600 -423177500 ] . x <= -1778463203
  [ 1155400 -144600 -10046900 ] . x <= 43312434
...
  [ 346800 558800 229200 ] . x <= 43326624
  [ 1457700 2361700 949200 ] . x <= 181949097

[SurfaceMesh (OK) #V=1051 #VN=0 #E=3147 #F=2098 #FN=0 E[IF]=3 E[IV]=5.98858 E[IFE]=2]
[PolygonalSurface #V=1051 #E=3147 #F=2098 Chi=2]
[ConvexCellComplex<3> #C=1 #F=2098 #V=1051 ]

Coarse model of Stanford bunny

Its convex hull with a precision 100

See also

QuickHull algorithm in arbitrary dimension for convex hull and Delaunay cell complex computation


#include "DGtal/base/Common.h"
#include "DGtal/geometry/volumes/ConvexityHelper.h"
#include "DGtal/shapes/SurfaceMesh.h"
#include "DGtal/io/writers/SurfaceMeshWriter.h"
#include "ConfigExamples.h"

double rand01() { return (double) rand() / (double) RAND_MAX; }

using namespace DGtal;
using namespace DGtal::Z3i;
int main( int argc, char* argv[] )
{
  int precision = argc > 1 ? atoi( argv[ 1 ] ) : 100;  // precision
  std::string inputFilename = argc > 2
    ? std::string( argv[ 2 ] )
    : examplesPath + "samples/bunny.dat" ;
  std::vector< RealPoint > points;
  std::ifstream finput( inputFilename.c_str() );
  std::string linestr;
  while ( std::getline( finput, linestr ) )
    {
      std::istringstream iss( linestr );
      double a, b, c;
      if ( ! (iss >> a >> b >> c) ) break;
      points.push_back( RealPoint( a, b, c ) );
    }
  trace.info() << "Read " << points.size() << " 3D points." << std::endl;

  // Build rational polytope
  typedef ConvexityHelper< 3 > Helper;
  const auto polytope
    = Helper::computeRationalPolytope( points, precision );
  trace.info() << polytope << std::endl;

  // Build the boundary of the convex hull as a surface mesh
  SurfaceMesh< RealPoint, RealVector > mesh;
  bool ok = Helper::computeConvexHullBoundary( mesh, points, precision );
  trace.info() << mesh << std::endl;
  std::ofstream out( "qhull-mesh.obj" );
  SurfaceMeshWriter< RealPoint, RealVector >::writeOBJ( out, mesh );
  out.close();

  // Build the boundary of the convex hull as a polygonal surface
  PolygonalSurface< RealPoint > polysurf;
  bool ok2 = Helper::computeConvexHullBoundary( polysurf, points, precision );
  trace.info() << polysurf << std::endl;

  // Build the convex hull as a convex cell complex.
  ConvexCellComplex< RealPoint > cvx_complex;
  bool ok3 = Helper::computeConvexHullCellComplex( cvx_complex, points, precision );
  trace.info() << cvx_complex << std::endl;

  return ( ok && ok2 && ok3 ) ? 0 : 1;
}
